Off-grid solar systems are an excellent way to make you self-sufficient in your energy needs as you are not relying on the grid for your energy needs. But the challenging part is to choose and maintain a good and efficient system. Although this type of grid system is made up of many components, when talking about efficiency and reliability batteries play an important role. In this article, we will discuss the batteries available for an off-grid solar system and figure out which one could be a perfect choice.
Basically, four major types of batteries are used:
Lead-acid batteries
Lithium-ion batteries
Flow batteries
Sodium Nickel Chloride batteries
Before diving deep into the Pros and Cons of various batteries used, let us know about the importance of batteries in the off-grid solar system:
The main purpose of the battery is to capture unused solar power so that it can be used at night or on low-sunlight days. Thus, the battery becomes the main source of power at night and low-sunlight days. Thus, the off-grid system batteries need to be energy efficient.
Lead-acid batteries are the conventional type of batteries and used globally for decades with reliability, despite being bulky. They are relatively cheap with well-established disposal and recycling processes. The life span of a battery is decided based on the charge cycle.
They can last up to 15 or more years if not held at elevated temperatures above 40 0 C and not regularly discharged too low. These batteries should be run to 50% depth of discharge and beyond that, their lifespan is negatively affected.
A sealed lead-acid battery might go through 300+ cycles in one year at a full-time residence but the same will go through 100 cycles in 4 years at a vacation home. There is no doubt that a battery with 100 cycles would be in much better shape.
The most favored advantage of lithium batteries is that they do not shut-down at a low voltage or low state of charge. This is an important factor to consider especially in emergencies or when a backup generator fails. Moreover, they are compatible with most of the invertors.
Lithium-ion batteries are relatively expensive to install but their maintenance cost is low.
Lithium-ion batteries can handle a deep discharge of 80% or more. Thus they are having a higher usable capacity and normally have a lifespan of 10 years but the end of life may be a concern for large lithium-ion batteries.
The fascinating feature is their efficiency, they are 95% efficient as compared to lead-acid batteries which have 85% efficiency. For example, if 1000 watts of solar is coming into batteries, lithium-ion store 950 watts as compared to 850 watts by lead-acid batteries.
Higher efficiency enables the battery to charge faster and can handle higher amperage from the charger. They work efficiently in both hot and cold climates. As a result, you may have to buy a few solar panels and a smaller backup generator.
Lithium batteries are less bulky as compared to lead-acid batteries. Their recycling and disposal system is not developed like lead-acid batteries. Their valuable materials need to be recovered to prevent toxic landfills but it is expected that the recycling process might improve owing to their increased use.
So far it seems that lithium-ion batteries are a better choice than lead-acid batteries. But let us have a look at some of the battery types new in technology than lithium-ion batteries.
Flow batteries are a promising alternative to lithium-ion batteries. They use pumped electrolytes (such as zinc bromide or vanadium ions) and chemical reactions to store charge and release it again. They leave no residual discharge and can be discharged to 100% of their capacity. Moreover, they do not lose charge and capacity over time and works well in high ambient temperatures. Their lifespan is the same as lithium-ion batteries, i.e. 10+ years. Surprisingly, though the technology is comparatively new, the recycling system is efficient than lithium-ion batteries.
They do not work well at a temperature lower than 15 0 C. They require frequent maintenance and expensive than lithium-ion batteries.
Sodium Nickel Chloride battery technology is another new technology that has several advantages over lithium-ion batteries. First of all, they have a broad temperature range -20 0 C to 60 0 C. Moreover, unlike larger lithium-ion battery systems, they do not require an internal cooling system.
They are fully recyclable, and manufacturing does not involve toxic or dangerous chemicals. But their lifespan is less compared to lithium-ion batteries, and they are more expensive to install.
Looking at all the factors, Lithium-ion batteries are still better than other battery types in terms of efficiency and performance. New technology batteries offer fascinating benefits to favor them, but they are quite expensive, and their reliability is not trusted yet.
